Precision Plane Speaker Mesh Laser Cutting Machine ML-EC6045

Application

Speaker mesh precision laser cutting machine is mainly used for laser micromachining of flat and curved surface speaker mesh of steel, aluminum, magnesium aluminum, titanium and other alloys

High Precision Machining
Small cutting seam width :

15 ~ 35um

High machining accuracy :

≤ ± 10um

Good quality of incision :

smooth incision, small heat affected zone, less burr and edge chipping < 15um

Size refinement :

the minimum product size is 100um

Spread the love

Loudspeaker Mesh Precision Laser Cutting Machine

Speaker mesh precision laser cutting machine can process materials such as steel, aluminum, magnesium aluminum, titanium, stainless steel, aluminum alloy and other materials for speaker mesh cutting and forming, shaft microhole forming, earphone opening forming, razor mesh cutting and forming, etc. . Such as notebook speaker network, mobile phone speaker network, audio speaker network, car speaker network, etc. The equipment is equipped with direct-drive mobile dual-drive precision motion table, visual positioning, automatic loading and unloading, and processing dynamic monitoring system, which truly realizes intelligent production management.



Equipment parameters
Maximum operating speed 1000mm/s(X) ;1000mm/s(Yl&Y2) ;50mm/s(Z)
Positioning accuracy ±3um(X)±3um(Y1Y2);±3um(Z)
Repetitive positioning accuracy ±lum (X) ;±lum(Y1&Y2) ;±3um(Z)
Machining material Alumina & zirconia & aluminum nitride & silicon nitride & Diamond & Sapphire & Silicon & gallium arsenide & tungsten steel, etc
Material wall thickness 0~2.0±0.02 mm
Plane machining range 450mm*600mm;(support customization for larger format requirements)
Laser type UV fiber laser
Laser wavelength 1030-1070±10nm
Laser power CW1000W&QCW150W& QCW300W& QCW450W for option
Equipment power supply 220V± 10%, 50Hz;AC 15A (main circuit breaker)
File format DXF、DWG&Gebar
Equipment dimensions 1280mm*1320mm*1600mm
Equipment weight 1500Kg
Strong adaptability
  • Have the ability of laser cutting, drilling, scribing, blind engraving and other fine machining technology for plane & regular curved surface instruments
  • Can machine FPC & PCB & PET & PI & copper foil & aluminum foil & carbon fiber & glass fiber & composite material & ceramic and other materials
  • Provide self-developed direct drive XY superposition type & split type fixed gantry precision motion platform & automatic loading and unloading system for option
  • Provide the function of pre scan of bilateral CCD vision location & automatic target grasping and location
  • Equipped with precision vacuum adsorption fixture & dust removal pipeline system
  • Equipped with self-developed 2D & 2.5D CAM software system for laser micromachining
Sample display

Huawei headset hole forming

Yoga930 & 940 & 950 shaft microporous forming

Razor mesh cutting and forming

Forming of aluminum alloy Harman arc surface horn mesh

Aluminum alloy speaker horn net forming

Conical hole type

Flexible design
  • Follow the design concept of ergonomics, delicate and concise
  • The combination of software and hardware functions is flexible, supporting personalized function configuration and intelligent production management
  • Support positive innovation design from component level to system level
  • Open control & laser micromachining software system easy to operate & intuitive interface
